Description
Passed The SAE Standards Endurance Test, 130 PSI Input Pressure & Delivery, Exhausted in a 4 Second Cycle +200,000 Times, Standard, Replacement for Bendix D-2™, All Ports 1/8 NPT, Includes 4 Plugs & Mounting Gasket, Pre-set at 125 PSI, For 130 PSI Use S-11874
Attribute
| Dimensions | |
| All Ports 1/8 NPT | |
| Popular Applications | |
| D-2 | |
| Truck Make | |
| Peterbilt, Kenworth, Volvo, Mack, International, Freightliner | |
| Weight | |
| 1.2 lb | |
| Specifications | |
| D-2 | |
| Our air governors are tested for air-pressure build-up, leakage, and unloader functionality. The D2 governor operates with the unloader mechanism of the compressor which automatically controls the air pressure in the air brake system between a minimum and maximum pressure. The compressor runs continually, but the compression of air is controlled by the governor. Lightweight Non-Metallic Internal Piston Lightweight Die-Cast Body Universal Mounting | |
| Cross Reference Number | |
| 275491, 102178275491, 276947, 277486, 9246 275491, 9246 275707, 9646 275491, 9646 275707, BW 275491, BW 275707, BW 275707N, NSN 2530008275934, TBB 61130255, TBB 61130933, WWS 275707, WWS 510B040010, WWS 70101-3404, WWS 70701-0003, 745-OR275491X, 745OR75491X, KN-18530, OR275491X, OR75491X, TR275491, VP 275491N, 410-986-C, BX275491, NS275491, ZZKN18530, BW 275491, 275491RX, KN-18530, 10900525, S-6106, 70101-3404, VP 275491N, 9754990070, STP275491 | |
